Features

– CLEANSTAR stainless steel satisfies chemical composition of JISG403 SUS316L.
– By advanced special melting processes, nonmetallic inclusion and gas component are severely controlled and significantly reduced to the minimum level.
– The corrosion resistance of our CLEANSTAR Stainless Steel is superior to the general and conventional stainless steel SUS316L.

Application

– Semiconductor manufacturing equipment parts
– Ultra-high vacuum equipment parts
– Medical related facilities parts
– Bio related facilities parts

Melting Processes

Grade Melting Prosess Mn,S,Al,gas components
CLEANSTAR-A VIM-VAR ↑ Lower
CLEANSTAR-B EAF-VAR
CLEANSTAR-C EAF

Chemical Composition (Example)

  C Si Mn P S Cu Ni Cr Mo Al N* O* H*
JISG4303
SUS316L		 0.030
max		 1.00
max		 2.00
max		 0.045
max		 0.030
max		 - 12.00 ~15.00 16.0~18.0 2.00~3.00 - - - -
CLEANSTAR-A 0.006 0.13 0.04 0.020 0.001 0.17 14.71 16.69 2.25 <0.002 65 10 1.6
CLEANSTAR-B 0.007 0.23 0.23 0.025 0.001 0.19 14.66 16.91 2.23 0.002 80 11 2.0
CLEANSTAR-C 0.012 0.38 0.45 0.026 0.004 0.20 12.15 16.85 2.03 0.002 160 49 3.0
SUS316L
(General)		 0.013 0.28 1.84 0.030 0.014 0.33 12.11 16.83 2.02 0.002 270 62 -

(mass%) *:ppm

  • 상품 정보

    상품 상세설명

    Features

    – CLEANSTAR stainless steel satisfies chemical composition of JISG403 SUS316L.
    – By advanced special melting processes, nonmetallic inclusion and gas component are severely controlled and significantly reduced to the minimum level.
    – The corrosion resistance of our CLEANSTAR Stainless Steel is superior to the general and conventional stainless steel SUS316L.

    Application

    – Semiconductor manufacturing equipment parts
    – Ultra-high vacuum equipment parts
    – Medical related facilities parts
    – Bio related facilities parts

    Melting Processes

    Grade Melting Prosess Mn,S,Al,gas components
    CLEANSTAR-A VIM-VAR ↑ Lower
    CLEANSTAR-B EAF-VAR
    CLEANSTAR-C EAF

    Chemical Composition (Example)

      C Si Mn P S Cu Ni Cr Mo Al N* O* H*
    JISG4303
    SUS316L    		 0.030
    max    		 1.00
    max    		 2.00
    max    		 0.045
    max    		 0.030
    max    		 - 12.00 ~15.00 16.0~18.0 2.00~3.00 - - - -
    CLEANSTAR-A 0.006 0.13 0.04 0.020 0.001 0.17 14.71 16.69 2.25 <0.002 65 10 1.6
    CLEANSTAR-B 0.007 0.23 0.23 0.025 0.001 0.19 14.66 16.91 2.23 0.002 80 11 2.0
    CLEANSTAR-C 0.012 0.38 0.45 0.026 0.004 0.20 12.15 16.85 2.03 0.002 160 49 3.0
    SUS316L
    (General)    		 0.013 0.28 1.84 0.030 0.014 0.33 12.11 16.83 2.02 0.002 270 62 -

    (mass%) *:ppm
